Product Overview

The WZPK Series Flanged Mineral Insulated Pt100 RTD Temperature Sensor is designed for industrial process temperature measurement in pipelines, tanks and process equipment.

The sensor features a removable mineral-insulated RTD insert installed inside a tapered stainless steel thermowell. The thermowell provides mechanical protection for the sensing element and allows the RTD insert to be removed for inspection, maintenance or replacement.

The Pt100 resistance element converts temperature changes into a resistance signal for compatible temperature measurement and control systems. The flanged connection provides a fixed installation interface for industrial process equipment.

Thermowell material, flange specifications, insertion length and RTD wiring configuration can be selected according to application requirements.

Applications

• Chemical processing equipment

• Petrochemical plants and process pipelines

• Oil and gas processing systems

• Power plants and thermal systems

• Boilers and steam-related process equipment

• Pressure vessels and industrial reactors

• Pharmaceutical production equipment

• Food processing systems, subject to material and hygiene requirements

• Industrial process automation systems

Key Features and Benefits

Removable RTD Insert

The replaceable sensing insert allows maintenance without removing the entire thermowell assembly, subject to the process installation and safety procedures.

Mineral-Insulated Construction

The armored RTD insert provides a compact structure suitable for industrial environments where mechanical durability and vibration resistance are important.

Tapered Thermowell Design

The tapered thermowell protects the sensing element from direct contact with the process medium. Its design can be selected according to process conditions and mechanical requirements.

Flanged Installation

The flange provides a fixed mounting interface for compatible pipelines, vessels and process equipment.

Stainless Steel Construction

SS316 thermowell construction is specified on the current product page. The RTD sheath material and flange material should be confirmed for the selected configuration.

Flexible RTD Wiring

Two-wire, three-wire or four-wire configurations can be selected according to the measurement system and accuracy requirements.

Customizable Configuration

Flange specifications, insertion length, RTD wiring and other confirmed design parameters can be customized according to customer requirements.

Technical Specifications

Note: Specifications can be customized according to customer requirements.

Configuration Options

The following configurations can be discussed during technical selection, subject to actual product availability:

• RTD Element: Pt100; single or dual element subject to confirmation

• Wiring: 2-wire, 3-wire or 4-wire

• RTD Sheath Material: SS304 or SS316

• Thermowell Material: SS316 as specified

• Flange: DN40 listed; confirm standard, pressure rating and facing

• Insertion Length: 350 mm listed; customized length subject to design

• Electrical Connection: 1/2" NPT listed

• Protection Grade: IP65 / IP67 subject to confirmation

Selection Guide

To select a suitable flanged Pt100 RTD sensor, please confirm:

1. Temperature Range: Minimum, normal and maximum process temperatures.

2. Process Conditions: Medium, operating pressure and flow conditions.

3. Flange Details: Size, standard, pressure rating and facing.

4. Insertion Length: Required insertion length and thermowell dimensions.

5. Sensor Configuration: Single or dual element, and 2-wire, 3-wire or 4-wire connection.

6. Materials: Required RTD sheath and thermowell materials based on the process medium.

7. Hazardous-Area Requirements: Required protection type and applicable certification, if installation is in a hazardous area.

FAQ

Q1: What is the function of the tapered thermowell?

It protects the RTD sensor from direct contact with the process medium.

Q2: Can the RTD insert be replaced?

Yes. The removable insert is designed for easier maintenance and replacement.

Q3: Does this product have a 4–20 mA output?

No. This is a Pt100 RTD sensor. A separate temperature transmitter is required for a 4–20 mA output.

Q4: Can the flange size and insertion length be customized?

Yes. Please provide your required flange specifications and insertion length.

Q5: Is this sensor explosion-proof?

An explosion-proof version is available if confirmed for the required configuration. Please contact us to confirm the applicable protection rating.

Q6: What information is needed for a quotation?

Please provide the temperature range, process medium, flange specifications, insertion length and quantity.

Request a Quotation

Please send us the following information for technical selection and quotation:

Required Information

• Model or product reference

• Temperature range

• Process medium and operating pressure

• Flange size, standard and pressure rating

• Required insertion length

• RTD element configuration and wiring

• Quantity

Special Requirements

• RTD sheath and thermowell materials

• Hazardous-area certification requirements

• Protection grade

• Special dimensions or installation conditions

JIECHUANG can review the application requirements and confirm a suitable configuration before quotation.
