Product Overview
The Stainless Steel Capillary Remote Reading Thermometer is a mechanical temperature measuring instrument designed for applications where direct temperature reading at the measurement point is difficult or inconvenient.
The thermometer uses a sensing bulb connected to the dial indicator through a flexible stainless steel capillary tube. Temperature changes at the sensing point are transmitted to the indicator, allowing operators to monitor process temperature from a remote location without additional power supply.
With stainless steel construction and customizable capillary length, this thermometer is suitable for industrial equipment, storage tanks, pipelines, boilers, and process systems requiring reliable remote temperature indication.
Applications
Boilers and Heating Equipment
Used for remote temperature monitoring where direct access is limited.
Storage Tanks
Suitable for temperature indication of liquid storage vessels.
Chemical Processing Equipment
Used with appropriate material selection for industrial process monitoring.
Heat Exchangers and Pipelines
Provides convenient temperature reading from a safe operating position.
Industrial Ovens and Furnaces
Suitable for high-temperature equipment monitoring.
Key Features and Benefits
1. Remote Temperature Reading Design
Allows temperature indication at a convenient location away from the measuring point.
2. Stainless Steel Construction
Provides durable performance for industrial environments.
3. Flexible Capillary Installation
The capillary tube enables installation where direct mounting is difficult.
4. No External Power Required
Mechanical temperature indication eliminates the need for electrical wiring.
5. Customizable Configuration
Dial size, stem length, capillary length, connection type, and materials can be selected according to application requirements.
6. Suitable for Harsh Industrial Conditions
Designed for temperature monitoring in process equipment, tanks, and pipelines.
Technical Specifications
Item | Specification |
Product Type | Stainless Steel Capillary Remote Reading Thermometer |
Display | Analog Pointer |
Dial Size | 60 mm/100mm Optional |
Temperature Range | 0-115ºC/32~240ºF,Customizable |
Scale | Dual Scale, °C/°F |
Capillary Length | 5 m, Customizable |
Process Connection | Thread/Flange Optional |
Mounting | Front Flange Optional |
Capillary Length | 100 mm,Customizable |
Stem Diameter | Φ10 mm,Customizable |
Material | Stainless Steel 304/316L Optional |
Filling | Dry / Liquid Filled Optional |
Accuracy | Class 1.6 |
Process Temperature | Customizable According to Application |
Ambient Temperature | Customizable According to Application |
Protection Rating | IP65 Optional |
Note: Specifications can be customized according to customer requirements.
Configuration Options
Available options include:
Dial diameter
Temperature range
Stem length
Capillary length
Process connection
Stem material
Case material
Selection Guide
Please provide:
Measuring range
Process temperature
Installation Requirements
Process Connection
Thread type
Flange requirement
Material Requirements
Medium characteristics
Corrosion requirements
FAQ
Q1: What is a remote reading thermometer?
A remote reading thermometer allows operators to read temperature from a distance by connecting the sensing bulb and dial indicator with a capillary tube.
Q2: Does this thermometer require electrical power?
No. It is a mechanical thermometer and does not require external power supply.
Q3: How long can the capillary tube be?
The capillary length can be customized according to installation requirements.
Please provide temperature range, capillary length, stem size, connection type, and application medium.
